Zenit BlueBOX - Lifting Station
Reliable wastewater and drainage management for homes, basements, and civil plants
The Zenit BlueBOX lifting stations are designed to collect and pump clear water, rainwater, and wastewater from areas located below the sewer line, such as garages, basements, and redeveloped spaces.
Made from durable polyethylene and optimised for Zenit BluePRO pumps, BlueBOX units provide a safe, cost-effective, and environmentally friendly solution when gravity drainage is not possible.
Available in multiple capacities, BlueBOX is ideal for both domestic installations and larger civil plants.
Models & Applications
- BlueBOX 60, 90, 150, 250 → For domestic and small residential systems, suitable for one pump
- BlueBOX 500 → For civil installations, supports two pumps for maximum reliability
Typical applications:
- Collection of wastewater from washing machines, sinks and WCs
- Rainwater drainage in underground or redeveloped spaces
- Sewage management when sewer access is distant or above floor level
Key Features
- Tank: Thick polyethylene tank reinforced with side ribs for strength and reliability. Lifting and carrying handles are integrated into the structure.
- Pipe connection: Arrangement for intake pipe connection on each side with standard dimensions engraved in the mould for precise wall drilling. Several tanks can be joined through a side duct to obtain multiple compositions and increase the total capacity of the system.
- Emergency emptying: Through-wall fitting for emergency emptying (standard). Possibility of installing a gate valve (optional).
- Floor fastening: Slots integrated in the structure for floor fastening. The system uses normal expansion plugs; no special brackets are required.
- Walk over cover: Sturdy walk-over cover (max. permissible load 100 kg) with gasket to guarantee a watertight seal against liquids and odours.
- Maximum level alarm float: Maximum level alarm float. (optional for blueBOX 60, 90 and 150 standard)
- Air venting system: Air venting system with activated carbon filter and ready for connection to external pipework DN40. The safety valve with a float ensures a tight closure of the pipeline if the level rises and prevents possible liquid spillage.
- Quick coupling system: Direct installation of the pump with a quick coupling system for the delivery pipe that allows the pump to be easily separated from the system for maintenance without disconnecting the pipes from the lifting station.
- Bottom coupling device (DAC): Installation with the bottom coupling device (DAC) allows the pump to be taken out quickly, even when the tank is full. The coupling device is installed by means of a movable plate and does not require any tank drilling.
- Extension: An extension element is available for the 250 and 500 models to raise the cover level by approximately 300 mm.
Automatic stop/start device
The motor is started and stopped by the float inside the pump or by an optional device that detects the liquid level in the tank.
Level sensor 4-20 mA
For constant detection of the liquid level and setting of the start/stop thresholds for the main and the secondary pump (if installed). It uses a standard 4-20 mA sensor housed inside the tank that can be removed by unscrewing a tightly sealed ring nut. Thanks to its wide reading range, it can use all the available volume while optimising operation.
Specifications
- Capacities: 60L, 90L, 150L, 250L, 500L
- Pump support: 1 pump (60–250), up to 2 pumps (500)
- Cover load: up to 100 kg pedestrian traffic
- Installation options: fixed, quick coupling, or DAC system
- Certification: EN 12050-1/2
Why Choose Zenit BlueBOX?
Whether you’re managing a basement laundry, a garage bathroom, or a civil wastewater plant, BlueBOX offers peace of mind, performance, and flexibility.
With its robust build, smart design, and certified reliability, the BlueBOX lifting station is the trusted solution for wastewater and drainage management across Europe.
