Zenit DRG Range - Submersible grey water drainage pump

Name: Zenit DRG Range - Submersible grey water drainage pump
Brand: T-T Pumps
SKU: 408

Zenit’s DRG from their Grey Range range of submersible drainage pumps features a cast iron channel impeller and free passage for large solids, making them the ideal pumps for industrial processes.

Zenit’s redesigned hydraulics and motors guarantee high performance, low consumption and outstanding versatility.

Need help finding the right solution?

Call our Specialist Advisers +44 (0)1630 647200

Model Options

Type	Product Code	Curve	Output		Discharge		Maximum		Weight kg	Datasheet	ATEX / Standard	Free Passage (mm)	Band	Price	Quantity	Delivery Status
Type	Product Code	Curve	Amps	kW	mm	inch	Head m	Capacity l/sec	Weight kg	Datasheet	ATEX / Standard	Free Passage (mm)	Band	Price	Quantity	Delivery Status
DRG 1750/6/250 C0HT 400V/3Ph	PZ/1668.001	A	27.6 amp13 kW	13	250 mm10 inch	10	Head16.5 mCapacity192 l/sec	192	319 kg	datasheet	Standard	100 x 70	B	£16,372.65
DRG 1000/6/250 H0HT 400V/3Ph	PZ/1674.001	A	15.7 amp7.5 kW	7.5	250 mm10 inch	10	Head13.6 mCapacity150 l/sec	150	270 kg	datasheet	Standard	80	B	£13,752.90
DRG 1000/6/250 C0HT 400V/3Ph	PZ/1665.001	A	15.7 amp7.5 kW	7.5	250 mm10 inch	10	Head11.5 mCapacity144 l/sec	144	302 kg	datasheet	Standard	100 x 70	B	£14,407.05
DRG 1750/6/200 A0HT 400V/3Ph	PZ/1664.001	A	27.6 amp13.6 kW	13.6	200 mm8 inch	8	Head17.2 mCapacity175 l/sec	175	293 kg	datasheet	Standard	100 x 70	B	£15,586.20
DRG 1000/6/200 B0HT 400V/3Ph	PZ/1670.001	A	15.7 amp7.5 kW	7.5	200 mm8 inch	8	Head14.4 mCapacity140 l/sec	140	239 kg	datasheet	Standard	80	B	£13,097.70
DRG 1000/6/200 A0HT 400V/3Ph	PZ/1663.001	A	15.7 amp7.5 kW	7.5	200 mm8 inch	8	Head12.2 mCapacity140 l/sec	140	276 kg	datasheet	Standard	100 x 70	B	£14,276.85
DRG 2000/4/250 H0HT 400V/3Ph	PZ/1673.001	A	30.8 amp15.0 kW	15.0	250 mm10 inch	10	Head18.1 mCapacity205 l/sec	205	282 kg	datasheet	Standard	80	B	£15,062.25
DRG 1500/4/250 H0HT 400V/3Ph	PZ/1672.001	A	20.5 amp11.0 kW	11.0	250 mm10 inch	10	Head13.3 mCapacity185 l/sec	185	270 kg	datasheet	Standard	80	B	£13,621.65
DRG 1200/4/250 H0HT 400V/3Ph	PZ/1671.001	A	17 amp9.0 kW	9.0	250 mm10 inch	10	Head11.3 mCapacity180 l/sec	180	270 kg	datasheet	Standard	80	B	£13,359.15
DRG 2000/4/200 B0HT 400V/3Ph	PZ/1669.001	A	30.8 amp15.0 kW	15.0	200 mm8 inch	8	Head18.1 mCapacity170 l/sec	170	251 kg	datasheet	Standard	80	B	£14,407.05
DRG 1500/4/200 B0HT 400V/3Ph	PZ/1667.001	A	20.5 amp11.0 kW	11.0	200 mm8 inch	8	Head13.9 mCapacity170 l/sec	170	239 kg	datasheet	Standard	80	B	£12,966.45
DRG 1200/4/200 B0HT 400V/3Ph	PZ/1666.001	A	17 amp9.0 kW	9.0	200 mm8 inch	8	Head11.9 mCapacity160 l/sec	160	239 kg	datasheet	Standard	80	B	£11,657.10
DRG 2000/4/150 A0HT 400V/3Ph	PZ/1662.001	A	30.8 amp15.0 kW	15.0	150 mm6 inch	6	Head26.1 mCapacity140 l/sec	140	224 kg	datasheet	Standard	80	B	£12,573.75
DRG 1500/4/150 A0HT 400V/3Ph	PZ/1661.001	A	20.5 amp11.0 kW	11.0	150 mm6 inch	6	Head17.1 mCapacity120 l/sec	120	212 kg	datasheet	Standard	80	B	£11,394.60
DRG 1200/4/150 A0HT 400V/3Ph	PZ/1660.001	A	17 amp9.0 kW	9.0	150 mm6 inch	6	Head13 mCapacity120 l/sec	120	212 kg	datasheet	Standard	80	B	£10,216.50
DRG 2000/4/100 B0HT 400V/3Ph	PZ/1675.001	A	30.8 amp15.0 kW	15.0	100 mm4 inch	4	Head20.7 mCapacity100 l/sec	100	212 kg	datasheet	Standard	80	B	£10,609.20
DRG 2000/4/100 A0HT 400V/3Ph	PZ/1659.001	A	30.8 amp15.0 kW	15.0	100 mm4 inch	4	Head26.6 mCapacity90 l/sec	90	212 kg	datasheet	Standard	80	B	£10,609.20
DRG 1500/4/100 A0HT 400V/3Ph	PZ/1658.001	A	20.5 amp11.0 kW	11.0	100 mm4 inch	4	Head18.2 mCapacity85 l/sec	85	200 kg	datasheet	Standard	80	B	£10,346.70
DRG 1200/4/100 H0HT 400V/3Ph	PZ/1657.003	A	17 amp9.0 kW	9.0	100 mm4 inch	4	Head22.4 mCapacity80 l/sec	80	195 kg	datasheet	Standard	80	B	£9,168.60
DRG 200/2/G50H A3AT 400V/3Ph	PZ/1806.200	A	3.3 amp1.5 kW	1.5	50 mm2 inch	2	Head17.4 mCapacity12 l/sec	12	28 kg	-	ATEX	15 x 10	B	£2,357.25
DRG 1200/4/80 D0HT 400V/3Ph	PZ/1676.001	A	17 amp9.0 kW	9.0	80 mm3 inch	3	Head24.6 mCapacity56 l/sec	56	183 kg	datasheet	Standard	65 x 60	B	£8,906.10
DRG 200/2/G50H A3AM 230V/1Ph	PZ/1807.200	A	9.3 amp1.5 kW	1.5	50 mm2 inch	2	Head17.4 mCapacity12 l/sec	12	28 kg	-	ATEX	15 x 10	B	£2,357.25
DRG 1000/4/80 D0GT 400V/3Ph	PZ/1904.003	A	15.8 amp7.5 kW	7.5	80 mm3 inch	3	Head22 mCapacity54 l/sec	54	141 kg	datasheet	Standard	65 x 60	B	£6,941.55
DRG 150/2/G50H A3AT 400V/3Ph	PZ/1804.200	A	2.4 amp1.1 kW	1.1	50 mm2 inch	2	Head13.3 mCapacity10 l/sec	10	27.5 kg	-	ATEX	15 x 10	B	£2,227.05
DRG 2500/2/80 G0HT 400V/3Ph	PZ/1678.003	A	32.9 amp18.5 kW	18.5	80 mm3 inch	3	Head48.3 mCapacity48 l/sec	48	165 kg	datasheet	Standard	75	B	£11,264.40
DRG 150/2/G50H A3AM 230V/1Ph	PZ/1805.200	A	6.6 amp1.1 kW	1.1	50 mm2 inch	2	Head13.3 mCapacity10 l/sec	10	27.5 kg	-	ATEX	15 x 10	B	£2,227.05
DRG 200/2/G50V A3AM 230V/1Ph	PZ/1803.200	A	9.3 amp1.5 kW	1.5	50 mm2 inch	2	Head17 mCapacity12 l/sec	12	27 kg	-	ATEX	15 x 10	B	£2,227.05
DRG 2000/2/80 G0HT 400V/3Ph	PZ/1677.002	A	26.2 amp15.0 kW	15.0	80 mm3 inch	3	Head45 mCapacity44 l/sec	44	155 kg	datasheet	Standard	75	B	£9,168.60
DRG 1500/2/80 B0GT 400V/3Ph	PZ/1903.003	A	19.5 amp11.0 kW	11.0	80 mm3 inch	3	Head41.7 mCapacity48 l/sec	48	105 kg	datasheet	Standard	55 x 50	B	£7,072.80
DRG 150/2/G50V A3AT 400V/3Ph	PZ/1800.200	A	2.4 amp1.1 kW	1.1	50 mm2 inch	2	Head13.3 mCapacity10 l/sec	10	26.5 kg	-	ATEX	15 x 10	B	£2,095.80
DRG 150/2/G50V A3AM 230V/1Ph	PZ/1801.200	A	6.6 amp1.1 kW	1.1	50 mm2 inch	2	Head13.3 mCapacity10 l/sec	10	26.5 kg	-	ATEX	15 x 10	B	£2,095.80
DRG 1500/2/80 A0GT 400V/3Ph	PZ/1901.003	A	19.5 amp11.0 kW	11.0	80 mm3 inch	3	Head46.5 mCapacity44 l/sec	44	105 kg	datasheet	Standard	40	B	£7,465.50
DRG 200/2/G50V A3AT 400V/3Ph	PZ/1802.200	A	3.3 amp1.5 kW	1.5	50 mm2 inch	2	Head17 mCapacity12 l/sec	12	27 kg	-	ATEX	15 x 10	B	£2,227.05
DRG 100/2/G40H A3AT 400V/3Ph	PZ/1798.200	A	1.7 amp0.75 kW	0.75	40 mm1½ inch	1½	Head14 mCapacity8 l/sec	8	26 kg	-	ATEX	15 x 10	B	£1,964.55
DRG 1200/2/80 B0GT 400V/3Ph	PZ/1902.003	A	16.1 amp9.0 kW	9.0	80 mm3 inch	3	Head35 mCapacity50 l/sec	50	104 kg	datasheet	Standard	55 x 50	B	£6,548.85
DRG 75/2/G40H A3AT 400V/3Ph	PZ/1796.200	A	1.4 amp0.55 kW	0.55	40 mm1½ inch	1½	Head11.1 mCapacity6 l/sec	6	25 kg	-	ATEX	15 x 10	B	£1,833.30
DRG 100/2/G40H A3AM 230V/1Ph	PZ/1799.200	A	4.9 amp0.75 kW	0.75	40 mm1½ inch	1½	Head14 mCapacity8 l/sec	8	26 kg	-	ATEX	15 x 10	B	£1,964.55
DRG 100/2/G40V A3AT 400V/3Ph	PZ/1794.200	A	1.7 amp0.75 kW	0.75	40 mm1½ inch	1½	Head14.2 mCapacity6 l/sec	6	25 kg	-	ATEX	15 x 10	B	£1,833.30
DRG 1200/2/80 A0GT 400V/3Ph	PZ/1900.003	A	16.1 amp9.0 kW	9.0	80 mm3 inch	3	Head42.8 mCapacity46 l/sec	46	104 kg	datasheet	Standard	40	B	£6,941.55
DRG 100/2/G40V A3AM 230V/1Ph	PZ/1795.200	A	4.9 amp0.75 kW	0.75	40 mm1½ inch	1½	Head14.2 mCapacity6 l/sec	6	25 kg	-	ATEX	15 x 10	B	£1,833.30
DRG 75/2/G40V A3AT 400V/3Ph	PZ/1792.200	A	1.4 amp0.55 kW	0.55	40 mm1½ inch	1½	Head10.9 mCapacity6 l/sec	6	24 kg	-	ATEX	15 x 10	B	£1,703.10
DRG 75/2/G40H A3AM 230V/1Ph	PZ/1797.200	A	4.2 amp0.55 kW	0.55	40 mm1½ inch	1½	Head11.1 mCapacity6 l/sec	6	25 kg	-	ATEX	15 x 10	B	£1,833.30
DRG 75/2/G40V A3AM 230V/1Ph	PZ/1793.200	A	4.2 amp0.55 kW	0.55	40 mm1½ inch	1½	Head10.9 mCapacity6 l/sec	6	24 kg	-	ATEX	15 x 10	B	£1,703.10
DRG 550/4/100 R0FT5 400V/3Ph	PZ/1521.002	A	8.4 amp4.0 kW	4.0	100 mm4 inch	4	Head13 mCapacity63 l/sec	63	90 kg	datasheet	Standard	65	B	£5,040.00
DRG 400/4/100 Y0ET5 400V 10M CABLE	PZ/1478.002	A	-	-	-	-	-	-	90 kg	datasheet	-	-	-	£3,856.00
DRG 400/4/100 U0ET5 400V/3Ph	PZ/1469.002	A	6.7 amp3.0 kW	3.0	100 mm4 inch	4	Head11.4 mCapacity41 l/sec	41	64 kg	datasheet	Standard	60	B	£3,583.00
DRG 300/4/100 U0ET5 400V/3Ph	PZ/1468.002	A	5.2 amp2.2 kW	2.2	100 mm4 inch	4	Head9.5 mCapacity38 l/sec	38	63.2 kg	datasheet	Standard	60	B	£3,556.00
DRG 200/4/100 T0ET 400V/3Ph	PZ/1472.002	A	3.4 amp1.5 kW	1.5	100 mm4 inch	4	Head8.7 mCapacity30 l/sec	30	58 kg	datasheet	Standard	45	B	£2,789.85
DRG 750/4/80 D0FT 400V/3Ph	PZ/1524.002	A	11.8 amp5.5 kW	5.5	80 mm3 inch	3	Head16.5 mCapacity58 l/sec	58	110 kg	datasheet	Standard	65 x 60	B	£6,156.15
DRG 550/4/80 D0FT5 400V/3Ph	PZ/1523.002	A	8.4 amp4.0 kW	4.0	80 mm3 inch	3	Head12.5 mCapacity52 l/sec	52	110 kg	datasheet	Standard	65 x 60	B	£4,632.00
DRG 400/4/80 H0ET 400V/3Ph	PZ/1466.002	A	6.7 amp3.0 kW	3.0	80 mm3 inch	3	Head14 mCapacity34 l/sec	34	61 kg	datasheet	Standard	75	B	£3,447.00
DRG 300/4/80 G0ET5 400V/3Ph	PZ/1463.002	A	5.1 amp2.2 kW	2.2	80 mm3 inch	3	Head12 mCapacity32 l/sec	32	60.2 kg	datasheet	Standard	75	B	£3,420.00
DRG 200/4/80 M0ET 400V/3Ph	PZ/1471.002	A	3.4 amp1.5 kW	1.5	80 mm3 inch	3	Head8.3 mCapacity19 l/sec	19	55 kg	datasheet	Standard	45	B	£2,658.60
DRG 1000/2/80 B0FT 400V/3Ph	PZ/1504.002	A	13.7 amp7.5 kW	7.5	80 mm3 inch	3	Head30.9 mCapacity48 l/sec	48	79 kg	datasheet	Standard	55 x 50	B	£6,024.90
DRG 1000/2/80 A0FT 400V/3Ph	PZ/1502.002	A	13.7 amp7.5 kW	7.5	80 mm3 inch	3	Head34 mCapacity45 l/sec	45	79 kg	datasheet	Standard	40	B	£6,024.90
DRG 750/2/80 B0FT 400V/3Ph	PZ/1505.003	A	10.8 amp5.5 kW	5.5	80 mm3 inch	3	Head22 mCapacity40 l/sec	40	71 kg	datasheet	Standard	55 x 50	B	£5,108.25
DRG 750/2/80 A0FT 400V/3Ph	PZ/1501.003	A	10.8 amp5.5 kW	5.5	80 mm3 inch	3	Head25 mCapacity40 l/sec	40	71 kg	datasheet	Standard	40	B	£4,977.00
DRG 550/2/80 B0FT 400V/3Ph	PZ/1503.002	A	7.7 amp4.0 kW	4.0	80 mm3 inch	3	Head17 mCapacity36 l/sec	36	68 kg	datasheet	Standard	55 x 50	B	£3,797.85
DRG 550/2/80 P0FT5 400V/3Ph	PZ/1540.002	A	7.7 amp4.0 kW	4.0	80 mm3 inch	3	Head24 mCapacity30 l/sec	30	63.6 kg	datasheet	Standard	40 x 35	B	£3,951.00
DRG 400/2/80 E0ET5 400V/3ph	PZ/1458.003	A	6.3 amp3.0 kW	3.0	80 mm3 inch	3	Head23.2 mCapacity28 l/sec	28	48 kg	datasheet	Standard	40 x 35	B	£3,038.00
DRG 300/2/80 E0ET 400V/3Ph	PZ/1457.005	A	4.6 amp2.2 kW	2.2	80 mm3 inch	3	Head18.4 mCapacity24 l/sec	24	45 kg	datasheet	Standard	40 x 35	B	£2,658.60
DRG 250/2/80 L0AT 400V/3Ph	PZ/1759.001	A	3.7 amp1.8 kW	1.8	80 mm3 inch	3	Head17 mCapacity24 l/sec	24	36 kg	datasheet	Standard	35 x 30	B	£2,227.05
DRG 400/2/65 A0ET 400V/3Ph	PZ/1433.002	A	6.4 amp3.0 kW	3.0	65 mm2½ inch	2½	Head22.8 mCapacity26 l/sec	26	47 kg	datasheet	Standard	40 x 35	B	£2,789.85
DRG 300/2/65 A0ET 400V/3Ph	PZ/1431.003	A	4.6 amp2.2 kW	2.2	65 mm2½ inch	2½	Head17.9 mCapacity24 l/sec	24	44 kg	datasheet	Standard	40 x 35	B	£2,528.40
DRG 250/2/65 B0AT 400V/3ph	PZ/1760.001	A	3.7 amp1.8 kW	1.8	65 mm2½ inch	2½	Head16.7 mCapacity22 l/sec	22	34 kg	datasheet	Standard	35 x 30	B	£2,095.80

Type	Product Code	Curve	Output		Discharge		Maximum		Weight kg	Datasheet	ATEX / Standard	Free Passage (mm)	Band	Price	Quantity	Delivery Status
Type	Product Code	Curve	Amps	kW	mm	inch	Head m	Capacity l/sec	Weight kg	Datasheet	ATEX / Standard	Free Passage (mm)	Band	Price	Quantity	Delivery Status
DRG 1750/6/250 C0HT 400V/3Ph	PZ/1668.001	A	27.6	13	250	10	16.5	192	319 kg	datasheet	Standard	100 x 70	B	£16,372.65
DRG 1000/6/250 H0HT 400V/3Ph	PZ/1674.001	A	15.7	7.5	250	10	13.6	150	270 kg	datasheet	Standard	80	B	£13,752.90
DRG 1000/6/250 C0HT 400V/3Ph	PZ/1665.001	A	15.7	7.5	250	10	11.5	144	302 kg	datasheet	Standard	100 x 70	B	£14,407.05
DRG 1750/6/200 A0HT 400V/3Ph	PZ/1664.001	A	27.6	13.6	200	8	17.2	175	293 kg	datasheet	Standard	100 x 70	B	£15,586.20
DRG 1000/6/200 B0HT 400V/3Ph	PZ/1670.001	A	15.7	7.5	200	8	14.4	140	239 kg	datasheet	Standard	80	B	£13,097.70
DRG 1000/6/200 A0HT 400V/3Ph	PZ/1663.001	A	15.7	7.5	200	8	12.2	140	276 kg	datasheet	Standard	100 x 70	B	£14,276.85
DRG 2000/4/250 H0HT 400V/3Ph	PZ/1673.001	A	30.8	15.0	250	10	18.1	205	282 kg	datasheet	Standard	80	B	£15,062.25
DRG 1500/4/250 H0HT 400V/3Ph	PZ/1672.001	A	20.5	11.0	250	10	13.3	185	270 kg	datasheet	Standard	80	B	£13,621.65
DRG 1200/4/250 H0HT 400V/3Ph	PZ/1671.001	A	17	9.0	250	10	11.3	180	270 kg	datasheet	Standard	80	B	£13,359.15
DRG 2000/4/200 B0HT 400V/3Ph	PZ/1669.001	A	30.8	15.0	200	8	18.1	170	251 kg	datasheet	Standard	80	B	£14,407.05
DRG 1500/4/200 B0HT 400V/3Ph	PZ/1667.001	A	20.5	11.0	200	8	13.9	170	239 kg	datasheet	Standard	80	B	£12,966.45
DRG 1200/4/200 B0HT 400V/3Ph	PZ/1666.001	A	17	9.0	200	8	11.9	160	239 kg	datasheet	Standard	80	B	£11,657.10
DRG 2000/4/150 A0HT 400V/3Ph	PZ/1662.001	A	30.8	15.0	150	6	26.1	140	224 kg	datasheet	Standard	80	B	£12,573.75
DRG 1500/4/150 A0HT 400V/3Ph	PZ/1661.001	A	20.5	11.0	150	6	17.1	120	212 kg	datasheet	Standard	80	B	£11,394.60
DRG 1200/4/150 A0HT 400V/3Ph	PZ/1660.001	A	17	9.0	150	6	13	120	212 kg	datasheet	Standard	80	B	£10,216.50
DRG 2000/4/100 B0HT 400V/3Ph	PZ/1675.001	A	30.8	15.0	100	4	20.7	100	212 kg	datasheet	Standard	80	B	£10,609.20
DRG 2000/4/100 A0HT 400V/3Ph	PZ/1659.001	A	30.8	15.0	100	4	26.6	90	212 kg	datasheet	Standard	80	B	£10,609.20
DRG 1500/4/100 A0HT 400V/3Ph	PZ/1658.001	A	20.5	11.0	100	4	18.2	85	200 kg	datasheet	Standard	80	B	£10,346.70
DRG 1200/4/100 H0HT 400V/3Ph	PZ/1657.003	A	17	9.0	100	4	22.4	80	195 kg	datasheet	Standard	80	B	£9,168.60
DRG 200/2/G50H A3AT 400V/3Ph	PZ/1806.200	A	3.3	1.5	50	2	17.4	12	28 kg	-	ATEX	15 x 10	B	£2,357.25
DRG 1200/4/80 D0HT 400V/3Ph	PZ/1676.001	A	17	9.0	80	3	24.6	56	183 kg	datasheet	Standard	65 x 60	B	£8,906.10
DRG 200/2/G50H A3AM 230V/1Ph	PZ/1807.200	A	9.3	1.5	50	2	17.4	12	28 kg	-	ATEX	15 x 10	B	£2,357.25
DRG 1000/4/80 D0GT 400V/3Ph	PZ/1904.003	A	15.8	7.5	80	3	22	54	141 kg	datasheet	Standard	65 x 60	B	£6,941.55
DRG 150/2/G50H A3AT 400V/3Ph	PZ/1804.200	A	2.4	1.1	50	2	13.3	10	27.5 kg	-	ATEX	15 x 10	B	£2,227.05
DRG 2500/2/80 G0HT 400V/3Ph	PZ/1678.003	A	32.9	18.5	80	3	48.3	48	165 kg	datasheet	Standard	75	B	£11,264.40
DRG 150/2/G50H A3AM 230V/1Ph	PZ/1805.200	A	6.6	1.1	50	2	13.3	10	27.5 kg	-	ATEX	15 x 10	B	£2,227.05
DRG 200/2/G50V A3AM 230V/1Ph	PZ/1803.200	A	9.3	1.5	50	2	17	12	27 kg	-	ATEX	15 x 10	B	£2,227.05
DRG 2000/2/80 G0HT 400V/3Ph	PZ/1677.002	A	26.2	15.0	80	3	45	44	155 kg	datasheet	Standard	75	B	£9,168.60
DRG 1500/2/80 B0GT 400V/3Ph	PZ/1903.003	A	19.5	11.0	80	3	41.7	48	105 kg	datasheet	Standard	55 x 50	B	£7,072.80
DRG 150/2/G50V A3AT 400V/3Ph	PZ/1800.200	A	2.4	1.1	50	2	13.3	10	26.5 kg	-	ATEX	15 x 10	B	£2,095.80
DRG 150/2/G50V A3AM 230V/1Ph	PZ/1801.200	A	6.6	1.1	50	2	13.3	10	26.5 kg	-	ATEX	15 x 10	B	£2,095.80
DRG 1500/2/80 A0GT 400V/3Ph	PZ/1901.003	A	19.5	11.0	80	3	46.5	44	105 kg	datasheet	Standard	40	B	£7,465.50
DRG 200/2/G50V A3AT 400V/3Ph	PZ/1802.200	A	3.3	1.5	50	2	17	12	27 kg	-	ATEX	15 x 10	B	£2,227.05
DRG 100/2/G40H A3AT 400V/3Ph	PZ/1798.200	A	1.7	0.75	40	1½	14	8	26 kg	-	ATEX	15 x 10	B	£1,964.55
DRG 1200/2/80 B0GT 400V/3Ph	PZ/1902.003	A	16.1	9.0	80	3	35	50	104 kg	datasheet	Standard	55 x 50	B	£6,548.85
DRG 75/2/G40H A3AT 400V/3Ph	PZ/1796.200	A	1.4	0.55	40	1½	11.1	6	25 kg	-	ATEX	15 x 10	B	£1,833.30
DRG 100/2/G40H A3AM 230V/1Ph	PZ/1799.200	A	4.9	0.75	40	1½	14	8	26 kg	-	ATEX	15 x 10	B	£1,964.55
DRG 100/2/G40V A3AT 400V/3Ph	PZ/1794.200	A	1.7	0.75	40	1½	14.2	6	25 kg	-	ATEX	15 x 10	B	£1,833.30
DRG 1200/2/80 A0GT 400V/3Ph	PZ/1900.003	A	16.1	9.0	80	3	42.8	46	104 kg	datasheet	Standard	40	B	£6,941.55
DRG 100/2/G40V A3AM 230V/1Ph	PZ/1795.200	A	4.9	0.75	40	1½	14.2	6	25 kg	-	ATEX	15 x 10	B	£1,833.30
DRG 75/2/G40V A3AT 400V/3Ph	PZ/1792.200	A	1.4	0.55	40	1½	10.9	6	24 kg	-	ATEX	15 x 10	B	£1,703.10
DRG 75/2/G40H A3AM 230V/1Ph	PZ/1797.200	A	4.2	0.55	40	1½	11.1	6	25 kg	-	ATEX	15 x 10	B	£1,833.30
DRG 75/2/G40V A3AM 230V/1Ph	PZ/1793.200	A	4.2	0.55	40	1½	10.9	6	24 kg	-	ATEX	15 x 10	B	£1,703.10
DRG 550/4/100 R0FT5 400V/3Ph	PZ/1521.002	A	8.4	4.0	100	4	13	63	90 kg	datasheet	Standard	65	B	£5,040.00
DRG 400/4/100 Y0ET5 400V 10M CABLE	PZ/1478.002	A	-	-	-	-	-	-	90 kg	datasheet	-	-	-	£3,856.00
DRG 400/4/100 U0ET5 400V/3Ph	PZ/1469.002	A	6.7	3.0	100	4	11.4	41	64 kg	datasheet	Standard	60	B	£3,583.00
DRG 300/4/100 U0ET5 400V/3Ph	PZ/1468.002	A	5.2	2.2	100	4	9.5	38	63.2 kg	datasheet	Standard	60	B	£3,556.00
DRG 200/4/100 T0ET 400V/3Ph	PZ/1472.002	A	3.4	1.5	100	4	8.7	30	58 kg	datasheet	Standard	45	B	£2,789.85
DRG 750/4/80 D0FT 400V/3Ph	PZ/1524.002	A	11.8	5.5	80	3	16.5	58	110 kg	datasheet	Standard	65 x 60	B	£6,156.15
DRG 550/4/80 D0FT5 400V/3Ph	PZ/1523.002	A	8.4	4.0	80	3	12.5	52	110 kg	datasheet	Standard	65 x 60	B	£4,632.00
DRG 400/4/80 H0ET 400V/3Ph	PZ/1466.002	A	6.7	3.0	80	3	14	34	61 kg	datasheet	Standard	75	B	£3,447.00
DRG 300/4/80 G0ET5 400V/3Ph	PZ/1463.002	A	5.1	2.2	80	3	12	32	60.2 kg	datasheet	Standard	75	B	£3,420.00
DRG 200/4/80 M0ET 400V/3Ph	PZ/1471.002	A	3.4	1.5	80	3	8.3	19	55 kg	datasheet	Standard	45	B	£2,658.60
DRG 1000/2/80 B0FT 400V/3Ph	PZ/1504.002	A	13.7	7.5	80	3	30.9	48	79 kg	datasheet	Standard	55 x 50	B	£6,024.90
DRG 1000/2/80 A0FT 400V/3Ph	PZ/1502.002	A	13.7	7.5	80	3	34	45	79 kg	datasheet	Standard	40	B	£6,024.90
DRG 750/2/80 B0FT 400V/3Ph	PZ/1505.003	A	10.8	5.5	80	3	22	40	71 kg	datasheet	Standard	55 x 50	B	£5,108.25
DRG 750/2/80 A0FT 400V/3Ph	PZ/1501.003	A	10.8	5.5	80	3	25	40	71 kg	datasheet	Standard	40	B	£4,977.00
DRG 550/2/80 B0FT 400V/3Ph	PZ/1503.002	A	7.7	4.0	80	3	17	36	68 kg	datasheet	Standard	55 x 50	B	£3,797.85
DRG 550/2/80 P0FT5 400V/3Ph	PZ/1540.002	A	7.7	4.0	80	3	24	30	63.6 kg	datasheet	Standard	40 x 35	B	£3,951.00
DRG 400/2/80 E0ET5 400V/3ph	PZ/1458.003	A	6.3	3.0	80	3	23.2	28	48 kg	datasheet	Standard	40 x 35	B	£3,038.00
DRG 300/2/80 E0ET 400V/3Ph	PZ/1457.005	A	4.6	2.2	80	3	18.4	24	45 kg	datasheet	Standard	40 x 35	B	£2,658.60
DRG 250/2/80 L0AT 400V/3Ph	PZ/1759.001	A	3.7	1.8	80	3	17	24	36 kg	datasheet	Standard	35 x 30	B	£2,227.05
DRG 400/2/65 A0ET 400V/3Ph	PZ/1433.002	A	6.4	3.0	65	2½	22.8	26	47 kg	datasheet	Standard	40 x 35	B	£2,789.85
DRG 300/2/65 A0ET 400V/3Ph	PZ/1431.003	A	4.6	2.2	65	2½	17.9	24	44 kg	datasheet	Standard	40 x 35	B	£2,528.40
DRG 250/2/65 B0AT 400V/3ph	PZ/1760.001	A	3.7	1.8	65	2½	16.7	22	34 kg	datasheet	Standard	35 x 30	B	£2,095.80

Orders placed by 3-00 pm have same working day dispatch and prompt delivery, normally next working day delivery, on selected models only.

Lead time applies

*10m cable weight not included.

Overview

Submersible Grey Water Drainage Pump

Need a high-performance submersible drainage pump? Learn about the Zenit DRG Range, which is intelligently made to drain grey water and perform in demanding industrial processes. These pumps are constructed using a heavy cast-iron channel impeller, which makes them superior in their solids-handling performance and very versatile in the most challenging applications.

Key Features of Zenit DRG

Heavy-duty cast iron construction ensures lasting durability for industrial and civil use.
Large solids handling: Suitable for water with large particles, making it perfect for process water and first rainfall tank drainage.
Single & Three-phase motors with Class H (180ºC) insulation for superior safety and longevity.
IP68 protection rating: Delivers peace of mind for fully submersible applications.
Dual silicon carbide mechanical seals in a large oil chamber maximise equipment lifespan.
Offered in 50Hz and 60Hz versions for broad compatibility.
DN32 to DN250 discharge sizes to accommodate various installation needs.
The AISI 431 drive shaft provides exceptional strength and corrosion resistance for reliable, long-term operation.

Applications

Civil lifting
Recirculation of industrial and process waters
Drainage and lifting of water from first rainfall tanks

Why Choose Zenit DRG from T-T Pumps?

Outstanding solids handling capacity
Energy-efficient, redesigned hydraulics and motors
Thermal protection for motor reliability
Fully repairable design for long-term value
Comes with a convenient 10m cable for easier installation

Upgrade your water management system with the versatile, efficient Zenit DRG submersible grey water drainage pump. Contact T-T Pumps today to find the perfect DRG model for your project and ensure robust, trouble-free drainage in any industrial or civil application.
